Key Parameters

Cell: LFP

Capacity: 552kWh/1204kWh

Rated Power: 500kW/1000kW

Rated Grid Voltage：AC400V, 3P3W

Communication Interface & Protocol: Ethernet, RS485；Modbus TCP/IP , Modbus-RTU

Size: 6058mm*2438mm*2896mm

Economy and high efficiency

DC BUS Netting Technology to eliminate the passive circulation between clusters, and the battery cluster capacity is 100% available;

Grately saving cost of the power part, and system efficiency increased by 2%.

Flexible scalability

Modular design of structure and components, multiple parallel connection and collaborative control;

Easy integrating with multi-type power source, such as solar, wind and diesel generators as per demands conveniently;

High compatibility with different brands, different manufacturing times, and even different specifications of the battery cluster.

High safety

200+ FMEA design optimization;

60+ security protection policies;

Modular intercluster security isolation technology;

Advanced model health assessment and risk warning technology.

Modular O&M

Modular O&M without interference in the normal operation of other modules for cost savings and utilization optimizing.

Vilion offers customized Battery Energy Storage System (BESS) solutions tailored to your project's specific application, providing flexible power and capacity options.
Application: frequency regulation, voltage support, renewable energy integration, peak load shifting, microgrid and backup power supply.
Charging/discharging rate: 1C, 0.5C, etc.

Cooling method: forced air cooling or liquid cooling.
Container type: 20ft, 30ft, 40ft.
